Specifications

Performance Characteristics
Decoder:
Card Operating Mode:
Interface:
Power Requirements:



Two Dimensional: PDF-417, Linear Barcodes: Code 39, Code 128
Hands-free, Manual Insertion
RS-232C Serial Port, RJ 45 - 10 Pin
36 ma @ 5VDC - Idle, 400mA maximum


Physical Characteristic
Dimensions:
Weight:
Card Size:
Housing:



2.25” H x 1.76” width x 4.79 D
170 grams (6.0 oz)
ISO Standard Size, 2.125" (53.98mm) x 3.375" (85.73 mm)
ABS plastic in Black or OEM color

User Environment
Operating  Temperature:
Humidity:


32o to 122o F (0o to 50o C)
10% to 90% (non-condensing)
