Specifications

Performance Characteristics

Decoder:
Card Operating Mode:
Interface:
Power Requirements:

Two Dimensional: PDF-417, Linear Barcodes: Code 39, Code 128
Hands-free, Manual Insertion
RS-232C Serial Port, USB 2.0 (FTDI Driver - Windows Certified)
36 ma @ 5VDC - Idle, 400mA maximum

Physical Characteristic

Dimensions:
Weight:
Card Size:
Housing:

2.13” H x 2.28” W x 4.33” D
210 grams
ISO Standard Size, 2.125" (53.98mm) x 3.375" (85.73 mm)
ABS plastic in Black or OEM color

User Environment
Operating Temperature:
Humidity:

32o to 122o F (0o to 50o C)
10% to 90% (non-condensing)
